Description
_
Product : MUSIC BOOK MAX ( BLACK )
Power amplifier IC : Japan Toshiba three-pole transistor
Op Amp IC : LM4562 + NE5532
ADI processor : USA ADI ADAU1452 ( Dual-core 64Bit /296MHz )
DSP processor : USA ADI AD1939
Audio capacitor : German Red Weimar Film Capacitors (including power supply system) / Japanese Chemical Electrolytic Capacitors
Immersion gold process PC board : SUPPORT
Aviation grade aluminum alloy : SUPPORT
Phone audio decoding : SUPPORT
Phone/computer tuning : SUPPORT ( optional / ASK US )
Operating voltage : DC 10.5V - 15V
Bluetooth : USA Qualcomm 5.0HD ( optional / ASK US )
High level input : 8 inputs ( switchable )
Low level input : 8 inputs
Low level output : 12 channel (RCA port output) 4V
Contrast switch : SUPPORT
Built-in 6 sound effects : SUPPORT
EQ adjustment : 31 Band 12 Channel
Output conversion : 2Ω / 4Ω
Output Power : RMS 8 X 50W @ 4Ω / 8 X 80W @ 2Ω . MAX 8 X 100W @ 4Ω / 8 X 160W @ 2Ω
Distortion : 0.01%
Signal to noise ratio : 116dB
External HD Bluetooth : SUPPORT
Two-way Karaoke : SUPPORT
Additional controller : SUPPORT
Optical input : SUPPORT
Coaxial input : SUPPORT
Actual Product Dimension : 280 x 250 x 55 mm
