GENERAL SPECIFICATION

• Speaker Type : 8" Active + 8" Passive
• Speaker Size : 203.2mm + 203.2mm
• Impedance : 2 Ohms
• RMS Power Rating : 300 Watts
• MAX Power Handling : 1200 Watts
• Sensitivity (1w/1m) : 83dB
• Frequency Response : 30Hz - 350H
• Box Measurement : W 22.7CM x L 30CM x H 23.4CM

AMPLIFIER SPECIFICATION

• Amplifier Class : Class D
• Amplifier Type : Subwoofer Monoblock
• Number of Channels : 1
• Minimum Impedance : 2 Ohm
• Signal to Noise Ratio : >80dB
• Efficiency @ 4 Ohm : 75%
• Total Harmonic Distortion (THD) : <0.5%
• Low Level Input Range : 200mv - 6V
• High Level Input : 2 - 9V
• Auto Turn-On : Yes (Hi-Level Input)
• Selectable X-Over : LPF Fixed
• X-Over Filter Range : 35Hz - 180Hz
• Bass Boost Range : 0 - 12dB
• Bass Boost Frequency : 50Hz
• Phase Selector : 0°~180°
• LED Indicator : Power | Protection
• Power Input Terminal Size : 8 GA
• Fuse Size : 30A
• Remote Level Control : Yes (SOLD SEPARATELY)
• Thermal Protection : Yes (>75°C)
• DC Output Protection : Yes (>2V)
• Short Circuit Output Protection : Yes
• Voltage Input Protection : Yes (>17vdc)

SPEAKER SPECIFICATION

• Voice Coil Diameter : 1.52" / 38.6mm
• Voice Coil Former Material : Aluminium
• Winding Material : Cooper
• Cone Material : Non-Pressed Paper
• Dust Cap Material : Paper
• Surround Material : Rubber
• Basket Material : Steel
• Magnet Material : Ferrite
• Magnet Weight : 32 Oz / 914 g
