PRODUCT SPECIFICATIONS
Speaker Type : 6.5" Active (x2) + 6x8 Passive
Speaker Size : 165.1mm (x2) + 154.2 x 203.2mm
Impedence : 2 Ohms
RMS Power Handling : 300 Watts
MAX Power Hnadling : 1200 Watts
Sensitivity Response : 30Hz - 350Hz
Voice Coil Diameter : 1.4" / 35.6mm
Voice Coil Former Material : Aluminium
Winding Material : Cooper
AMPLIFIER SPECIFICATIONS
Amplifier Class : Class D
Amplifier Type : Subwoofer Monoblock
Number Of Channel : 1
Minimum Impedence : 2 Ohms
Signal to Noise Ratio : >80db
Efficiency @ 4 Ohms : 75%
Total Harmonic Distortion (THD) : <0.5%
Low Level Input Range : 200mv - 6v
High Level Inpu : 2 - 9v
Auto Turn ON : YES (Hi-Level Input)
Selectable X-Over : LPH Fixed
X-Over Filter Range : 35Hz -180Hz
Bass Boost Rnage : 0 - 12dB
Bass Boost Frequency : 50Hz
Phase Selector : 0°~180°
LED Indicator : Power l Protection
Power Input Terminal Size : 8GA
Fuse Size : 30A
Remote Control : Yes (Included)
Thermal Protection : Yes (>75°C)
DC Output Protection : Yes (>2V)
Short Circuit Output Protection : Yes
Voltage Input Protection : Yes (>17vdc)
BOX SPECIFICATIONS.
Internal Volume : 10.8L / 0.38 ft3
Box Tune : 50Hz
Load Configuration : Parellel In
Box Type : Passive Active (Sealed)
Box Material : Aluminium
Finish Material : Anodic Black
-3dB DroppingPoint : 35Hz
MEASUREMENT
Overall Height : 9' / 230mm
Overall Width : 9" / 230mm
Overall Depth : 12" / 304mm
